Technical Data of FX Series All In One Solar Street Light
FX solar street light is the latest OEM LED solar street lamp. This all in one LED solar street light has high-cost performance, novel style, a new battery and high-quality lamp beads, which are popular all over the world and meet the aesthetic needs of mass customers.
- Introduction
- Main features
- Specifications
- Recommended
Product Introduction
FX solar street light is the latest OEM LED solar street lamp. This all in one LED solar street light has high-cost performance, novel style, a new battery and high-quality lamp beads, which are popular all over the world and meet the aesthetic needs of mass customers.
Main features
Features:
● High-power LED chip, high luminous efficiency.
● High-efficiency solar panel, better conversion rate, longer life span.
● High-efficiency lithium battery, longer life span, more stable.
● Intelligent controller with PIR sensor, more energy-saving.
Specifications
| Technical Data of FX Series All In One Solar Street Light | ||||||
| MODEL | FX-40W | FX-50W | FX-60W | FX-80W | FX-100W | FX-120W |
| Application | ROAD | |||||
| Color Temperature(CCT) | 2000-7000K(customized available) | |||||
| IP Rating | IP66 | |||||
| Beam Angle(°) | 140*70° | |||||
| CRI (Ra>) | 80 | |||||
| Input Voltage(V) | DC 12V | |||||
| Lamp Luminous Efficiency(lm/w) | 170Lm/w | |||||
| Lamp Luminous Flux(lm) | 6800LM | 8500LM | 10200LM | 13600LM | 17000LM | 20400LM |
| Warranty(Year) | 3-Year | |||||
| Working Temperature(℃) | -90 | |||||
| Color Rendering Index(Ra) | 80 | 70 | 70 | 70 | 70 | 70 |
| Certification | RoHS, CE, IP66, IK09, IEC | |||||
| Power Supply | Solar | |||||
| Light Source | LED | |||||
| Support Dimmer | Yes | |||||
| Lighting solutions service | Lighting and circuitry design, Project Installation | |||||
| Lifespan (hours) | 100000 | |||||
| Working Time (hours) | 100000 | |||||
| Lamp Body Material | High class aluminium alloy | |||||
| Solar Panel | 18V 65W High efficiency Monocrystalline silicon | 18V 70W High efficiency Monocrystalline silicon | 18V 80W High efficiency Monocrystalline silicon | 18V 100W High efficiency Monocrystalline silicon | 18V 130W High efficiency Monocrystalline silicon | 18V 140W High efficiency Monocrystalline silicon |
| LED | USA Bridgelux 3030 Chips | |||||
| Battery Type | 12.8V 30AH Powerful LifePO4 battery | 12.8V 36AH Powerful LifePO4 battery | 12.8V 48AH Powerful LifePO4 battery | 12.8V 54AH Powerful LifePO4 battery | 12.8V 66AH Powerful LifePO4 battery | 12.8V 72AH Powerful LifePO4 battery |
| Discharge time | 12hour/Day, backup 5-7 days | |||||
| Photoelectric conversion efficiency | 21% | |||||
| Charging time | 5-6 Hours | |||||
| Install height | 6-7m | 7-8m | 6-8m | 8-9m | 9-10m | 10-12m |
| Lighting Mode | Dusk to dawn + Time controll + motion sensor (cuztomize is available) | |||||
